UL486A-486B          NMX-J-543-ANCE-03           C22.2 No.65-03



WIRE / CABLE  TYPES, CLASSES and SIZES

COVERED BY THE STANDARD ABOVE.
OTHER TYPES OF WIRE SUCH AS CLASS K "FLEX" WIRE (NOT LISTED HERE)
ARE ONLY PERMITTED BY SPECIFIC ADDITIONAL TESTING


International Hydraulics Inc. brand Listed Lugs have been UL486 tested and approved for flex (flexible) fine stranded wires of class G, class H, class I, metric class 5, DLO (Diesel Locomotive) and class k (MTW / welding wire / battery wire)


Use this chart in conjunction with wire ranges marked on

LUGS &/or PRODUCT LABEL FOR ACCEPTABLE WIRE TYPES AND SIZES

REF:Standard AVAILABLE from: http://ulstandards.ul.com/

THIS CHART BELOW IS A GENERAL INFORMATION GUIDE ONLY. E&OE.


WIRE STRANDING TYPE / CLASS

WIRE MATERIAL



COPPER

ALUMINUM

AWG SOLID

30 AWG (.05mm2) to 10 AWG (5.3mm2)

12 AWG (3.3mm2) and 10 AWG (5.3mm2)

AWG STRANDED

CLASS B CONECENTRIC, COMPRESSED

30 AWG (.05mm2) to 2000 kcmil (1010mm2)

12 AWG (3.3mm2) to 2000 kcmil (1010mm2)

AWG STRANDED

COMPACT UNIDIRECTIONAL LAY

USA: 2 AWG (33.6mm2) & LARGER

 CANADA & MEXICO: 8 AWG (8.4mm2) & LARGER



12 AWG (3.3mm2) to 2000 kcmil (1010mm2)

SIW (SINGLE INPUT WIRE) STRANDED - 12 AWG (3.3mm2) to 1000 kcmil (508mm2)
AWG STRANDED

CLASS C CONCENTRIC

kcmil(1010mm2)

-

METRIC

SOLID & STRANDED

FALLING WITHIN THE ABOVE SIZE RANGES

FALLING WITHIN THE ABOVE SIZE RANGES

COPPER CLAD ALUMINUM (USA ONLY).
NOT ALLOWED FOR CANADA, OR MEXICO
- 12 AWG (3.3mm2) and 10 AWG (5.3mm2) SOLID

12 AWG (3.3mm2) to 2000 kcmil (1010mm2)
STRANDED CLASS B CONCENTRIC, COMPRESSED and CLASS C CONCENTRIC
